H07Z-U
Single Core non-sheathed cable with Halogen-Free Cross Linked Insulation
APPLICATION
For indoor connection in rooms, in equipments, in control cabinets & are suitable for wiring when a low smoke and fumes is required and good behaviour with temperature are required
Construction
| Conductor | Round Solid Annealed Copper as per class 1 of BS EN 60228 |
|---|---|
| Insulation | XLHF applied around the conductor 90c |
| Colors | Color: Red ,Yellow ,Blue ,Black, Grey, Brown,White, Y/G Any other color can be supplied on request |
| Packing | Wires are rolled and wrapped into coils of 100 Yards/Meters |
Ratings
| Temperature | - 25 C to + 90 C |
|---|---|
| Voltage | 300/500 V, 450/750 V |
| Applicable Standards | BS EN 60228, BS EN 50525-3-41 |
| Flame Retardant | BS EN 60332-1 |
| Low Smoke Halogen free | BS EN 60754-1/2, BS EN 61034-1/2 |
Conductor Flexibility Class 1 BS EN 60228
Rated Voltage As Per the table
Minimum Bending Radius (mm) 12 x Overall Diameter
Max conductor Temp in service 90 CMax conductor Temp in service 90 C
Max. short-circuit temperature: 250°C Minimum installation and handling temperature: 5ºC
Flame retardant IEC 60332-1-2
